What it is?
This vintage DIY electronic kit is a light organ with 3 projectors (bulbs), with the light effects rate adjustable by a rotary knob. The bulbs will light up depending on the intensity of the input signal and its frequency, producing special lighting effects.
How does the circuit work?
The wiring diagram comprises four parts: a preamplifier, a medium frequency separator stage, a low frequency separator stage and a low frequency separator stage. Each part of the electronic scheme is described in detail in the following:
- The preamplifier composed of transistors T1 and T2, has the role of amplifying the signal taken from a radio (output from detection)
- The low frequency separator stage consists of a "low pass" filter (R5, R6, C5, C6) and an amplification stage (T3, T4)
- Medium frequency separator stage, consisting of a "bandpass" filter (C8, R10, R11, R12, C9) and an amplification stage (T6, T7)
- High frequency separator stage, consisting of a "pass up" filter (C11, R16, R17) and an amplification stage (T9, T10)
In the collectors of transistors T7, T8, T11 the electric lamps are connected as follows:
The red light bulb at T5, the yellow light bulb at T8 and the green light bulb at T11 (of course you can use any color you want). With an audio frequency signal from the radio, cassette player, pick-up, mp3, PC, laptop (from the line output: 500mV) you can act directly from point A, breaking the ab connection. The light intensity of the bulbs and their operating dynamics are adjusted with the help of the P potentiometer (5 KOhmi). The assembly is powered by a 9V battery or DC voltage source.
The red light bulb at T5, the yellow light bulb at T8 and the green light bulb at T11 (of course you can use any color you want). With an audio frequency signal from the radio, cassette player, pick-up, mp3, PC, laptop (from the line output: 500mV) you can act directly from point A, breaking the ab connection. The light intensity of the bulbs and their operating dynamics are adjusted with the help of the P potentiometer (5 KOhmi). The assembly is powered by a 9V battery or DC voltage source.
Technical characteristics of the assembly
- Supply voltage: 9V
- Maximum current consumption: 300mA
- Input sensitivity: approx. 20mV
- Input impedance: approx. 100 KOhm
- Electric bulbs: 75mA / 9V
- Frequency band in which the filters work:
- Channel I (low frequencies): 50 - 500Hz
- Channel II (medium frequencies): 500 - 2000Hz
- Channel III (high frequencies): 2000 - 16000Hz
This vintage DIY electronic kit came with a set of polystyrene boards and a soldering solution (toluene). With their help, the box in which the electric lamps and the electronic assembly are subsequently mounted is made. With a metal or wood object, the soldering solution was spread in a thin layer on the edges to be glued, after which the plates were placed according to the drawing in the leaflet. For proper gluing of the box, it must be left to dry for 24 hours.
List of required components (with recent equivalents):
- T1, T3, T4, T6, T7, T9, T10 - BSNC 1 transistors (BC 170) or BC 337 / 2N2222
- T2 - transistor BC 170 C or BC 337 / 2N2222
- T5, T8, T11 - BSND 1 transistors (BD 135, BD 233) or BD 137 / BD 139
- Cl - capacitor - 0,22 uF / 10V min.
- C3 - capacitor - 4,7 uF / 10V min.
- C2, C9 - capacitors - 47 nF / 10V min.
- C8 - capacitor - 0,1 uF / 10V min.
- C11 - capacitor - 1,5 nF / 10V min.
- C6 - capacitor - 0,47 uF / 10V min.
- C4, C5, C7, C10, C12 - capacitors - 10uF / 10V min.
- R1 - resistor - 1 MOhm / 0,125W min.
- R3 - resistor - 330 KOhm / 0,125W min.
- R2, R4, R9, R12, R15, R20 - resistors - 1 KOhm / 0,125W min. or 1.2 KOhm / 0,25W
- R5, R8, R11, R14, R19 - resistors - 2,2 KOhm / 0,125W min.
- R6 - resistor - 22 KOhm / 0,125W min.
- R7, R13, R18 - resistors - 10 KOhm / 0,125W min.
- R10 - resistor 680 Ohm / 0,125W min
- R16 - resistor 150 KOhm / 0,125W min.
- R17 - resistor 4,7 KOhm / 0,125W min.
- Semi-adjustable linear - 5 KOhm
- Electric bulbs: 75mA / 9V (3. pcs) -> See here how to replace the original 9V / 75mA bulbs, ie approx. 4W with a group of LEDs.
- Printed wiring or breadboard test board
- Tin or connecting threads
Download the original IPRS leaflet Baneasa 8202
For a better understanding of the operation of the circuit we will need electronic scheme presented below:
In order to carry out this project in our own laboratory, we will also need printed wiring PCB layout From lower:
This electronic kit has often been used by innovative amateur electronics designers to design modified light organs. Thus, almost every electronics engineer at that time (since 1983) used this kit as a base in construction of improved light organs (modified).
I have attached below an image with an improved light organ, which uses this electronic kit as a basic assembly:
Many of you are probably wondering how this DIY electronic kit was packaged or distributed. Below I have attached some pictures with the packaged product (new), the contents of the envelope and two pictures with the assembled product. Thanks Mr. Marius Balauta and also Mr. George-Alexandru Marinescu for providing pictures!
Another example of Modified "light organ", we have it below, where in the box were crammed a small transformer, a rectifier bridge, three thyristors, three potentiometers for each channel, plus a general potentiometer and obviously the kit presented. The project was carried out in 1984 by Mister. My Daniel.
